Laser Chiller Rau 3W-5W Khoom- xeev UV Lasers
Khoom Description
Lub CWUL-05 UV laser chiller yog tsim tshwj xeeb rau 3W-5W khoom- xeev UV lasers; featuring ib tug compact qauv thiab me me hneev taw, nws yog portable heev. Lub CWUL-05 UV laser chiller los ntawm Teyu yog dav siv thoob plaws ntau yam kev lag luam, suav nrog nyias- zaj duab xis etching, precision marking, iav marking, khoom micromachining, wafer txiav, 3D luam ntawv sai prototyping, thiab zaub mov ntim khoom. Nws cov yam ntxwv tseem ceeb suav nrog: lub peev xwm ua kom txias ntawm 430W siv eco-cov tub yees tus phooj ywg; ruaj khov ua haujlwm txias thiab cov neeg siv- ua haujlwm zoo; thiab siab - tswj qhov kub thiab txias. Lub tshuab ntsuas kub ntse muaj ob hom kev tswj qhov kub thiab txias, nrog rau ntau qhov kev teeb tsa thiab kev ua haujlwm tsis raug. Tsis tas li ntawd, nws suav nrog ntau yam kev tiv thaiv lub tswb, xws li lub sijhawm compressor- ncua kev tiv thaiv, tiv thaiv dhau tam sim no, ceeb toom dej ntws, thiab lub tswb ntsuas kub / qis. Tau tshaj lub zog specifications thoob plaws ntau lub teb chaws, chav tsev tuav ntawv pov thawj nrog rau ISO9001, CE, RoHS, thiab REACH; xaiv cov khoom siv ntxiv, xws li lub rhaub dej thiab lim dej lim dej, kuj muaj.
Khoom Parameters
| Qauv | CWJ-05AH | CWJ-05BH | CWJ-05 DH |
| Qhov hluav taws xob | AC 1P 220 ~ 240V | AC 1P 220 ~ 240V | AC 1P 110V |
| Ntau zaus | 50 Hz | 60 Hz | 60 Hz |
| Tam sim no | 0.5~3.1A | 0.5~4A | 0.5~7.4A |
| Max. siv zog | 0.76 kWm | 0.74 kWm | 0.8 kWm |
| Compressor zog | 0.18 kWm | 0.17 kWm | 0.21 kWm |
| 0.24 hp ib | 0.22 hp ib | 0.28 hp ib | |
| Nominal txias muaj peev xwm | 1296 Btu/h | ||
| 0.38 kWm | |||
| 326 Kcal / h | |||
| Cov tub yees | R-134a/R-32 | R-134a | |
| Precision | ± 0.3 degree | ||
| Reducer | Capillary kab mob | ||
| Lub tshuab fais fab | 0.05 kWm | ||
| Tank muaj peev xwm | 8L | ||
| Inlet thiab qhov hluav taws xob | Rp 1/2" | ||
| Max. twj tso kua mis | 12m | ||
| Rated ntws | 8L / min | ||
| N.W. | 19kg ua | 18kg ua | |
| G.W. | 21kg ua | 20kg ua | |
| Dimension | 58 × 29 × 52 cm (L × W × H) | ||
| Pob dimension | 65 × 36 × 56 cm (L × W × H) | ||
Cov Khoom Zoo
Cov khoom siv
Cim npe nrov: laser chiller rau 3w-5w khoom- xeev uv lasers, ua nyob rau hauv Suav teb, lwm tus neeg Tuam Tshoj, manufacturers, luv nqi, yuav, pheej yig, luv nqi
